MT6701CT 14-Bit Magnetic Angle Sensor

NOVOSENSE·Magnetic Angle Position Sensor·ActiveNew & Original

MT6701CT 14-Bit Magnetic Angle Sensor
US$1.0702
Order quantityUnit priceTerms
1-9US$1.9338EXW
10-29US$1.611EXW
30-99US$1.4094EXW
100-499US$1.2029EXW
500-999US$1.1095EXW
1000+US$1.0702EXW

Prices are indicative starting points — send your BOM and target quantity for an exact quotation. · FOB / DDP on request

  • New & Original — date-code photo and documentation with every shipment
  • Lead time on request
  • MOQ 1 pc — flexible for prototypes and production runs
  • Tape & reel / cut tape and custom packaging available
  • Magnetic Angle Position Sensor line — availability, approved alternates and pricing checked line by line
Get A Quote Back to Parts

Specifications

ManufacturerNOVOSENSE
Manufacturer part numberMT6701CT-AKD-R
CategoryMagnetic Angle Position Sensor
DescriptionNOVOSENSE MT6701 differential Hall angle position sensor with 14-bit absolute angle, I2C, SSI, ABZ, UVW, PWM and analog outputs, on-chip EEPROM and stray-field immunity for robotic joint and BLDC commutation feedback.
Package / caseSOP-8
Mounting typeSMD
ConditionNew & Original
Supply3.3-5 V
Resolution14-bit absolute
InterfacesI2C / SSI / ABZ / UVW / PWM / Analog
Max speed55000 RPM
Temp-40 to 125 C

Availability & supply

StockSourced to order
Minimum order (MOQ)1 pc
Lead timeLead time on request
Unit price1-9: US$1.9338 · 10-29: US$1.611 · 30-99: US$1.4094 · 100-499: US$1.2029 · 500-999: US$1.1095 · 1000+: US$1.0702
PackagingTape & reel per manufacturer standard
NotesLCSC product code C19711153; contactless 0-360 degree encoder replacing optical encoders in robot joints and closed-loop stepper drives; LCSC USD ladder, verify at quote

Alternatives & cross-references

Pin-compatible
Ask us — we source cross-references on request.
Same spec · other brand
Ask us — we source cross-references on request.
Functional equivalent
Ask us — we source cross-references on request.

Quality & compliance

Traceability
Every line ships with manufacturer / distributor documentation and a date-code photo taken before dispatch.
Incoming inspection
Parts checked for marking, packaging and count on receipt; X-ray / decapsulation available on request for high-value lines.
Certificates on request
COC / COA / RoHS declaration issued with the shipment. Full lot traceability kept for 24 months.
